Thunderbolt PRO Galvanised Countersunk Masonry Screw Anchors

Code
Thunderbolt PRO Galvanised Countersunk Masonry Screw Anchors
  • Optimum high-performance concrete and masonry screw bolt anchor
  • Stamped head markings for easy identification and traceability
  • Fast installation at reduced torque
  • No expansion, ideal for close to edge applications
  • Suitable for installation with impact drivers
  • Removable
Stock Availability
Grouped product items
DescriptionCodePER Stock Qty
6MM X 50MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS06050G)
SXTBCS06050G
EA
-
6MM X 75MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS06075G)
SXTBCS06075G
EA
-
8MM X 75MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS08075G)
SXTBCS08075G
EA
-
8MM X 100MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS08100G)
SXTBCS08100G
EA
-
10MM X 75MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS10075G)
SXTBCS10075G
EA
-
10MM X 100MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS10100G)
SXTBCS10100G
EA
-
12MM X 85MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS12085G)
SXTBCS12085G
EA
-
12MM X 100MM THUNDERBOLT PRO COUNTERSUNK HEAD GAL
(SXTBCS12100G)
SXTBCS12100G
EA
-
Product Description

ICCONS® Thunderbolt®PRO Countersunk Head is the latest high tensile screw-in, self-tapping concrete and masonry screw anchor for use in a wide range of applications found in the residential, commercial and infrastructure construction spaces. The Thunderbolt®PRO is the most complete screw-bolt range on the market with the entire range AS5216:2021 Compliant, ETA assessments for cracked concrete, fire performance and seismic ratings (please see technical data for specification requirements).

Installation is quick and easy, simply drill, clean the hole and screw in the anchor. The Thunderbolt®PRO can be easily removed and does not leave residue or metal components in the drilled hole that can cause corrosion. Available in zinc and galvanised finishes, both hex and countersunk head styles and ranging from 5mm to 18mm in various lengths, ICCONS® new and improved Thunderbolt®PRO is the anchor for all applications.

ICCONS Thunderbolt®Pro achieves the Highest Loads while generating Low Expansion forces which can make it a great alternative to adhesive anchors. The Thunderbolt®Pro is also completely removable making it ideal for temporary applications. Unlike mechanical expansion anchors, the Thunderbolt®Pro keys into the base material for the entire depth and diameter of the hole, not just at the base of the hole. This reduces high-energy forces within the concrete allowing close anchor spacing and near-to edge anchor locations. Ten sharp thread-forming teeth ensure the most secure connection in hard base materials. The Thunderbolt®Pro is a truly versatile anchor, as it can be installed in whole range of base materials such as concrete, block, brick, timber, marble, and stone, just to name a few. The precisely engineered design of ICCONS Thunderbolt®Pro is the result of extensive testing and provides market leading load performance. ICCONS Thunderbolt®Pro is a one-piece, fast, efficient and cost-effective fixing solution for any job.

Features

  • Optimum high-performance concrete and masonry screw bolt anchor
  • AS 5216 compliant
  • ETA assessed for cracked concrete and fire performance
  • Countersunk head design with “lightning bolt” locking serrations for a secure fix
  • Stamped head markings for easy identification and traceability
  • Fast installation at reduced torque
  • No expansion, ideal for close to edge applications
  • Suitable for installation with impact drivers
  • Removable
  • Available on ICCONS Designfix software

Applications

  • Structural fixings in cracked and uncracked concrete
  • Tunnel fit out
  • Cable tray support systems
  • Seismic bracing of MEP systems
  • Fastening steel strut channel and support straps for MEP
  • Facade structures
  • Guard rails
  • Bollards and protective barriers
  • Machinery and plant equipment
  • Stadium and theatre seating
  • Acoustic barriers
  • Balustrades and handrails
  • Scaffolding ties
  • Formwork
  • Plumbing and fire services
  • Steel frame construction
  • Timber frame construction
  • Glazing, windows and storefronts
  • Racking and shelving
  • Fixings wood structures in concrete
